How to Choose the Right Size Concrete Mixer for Your Construction Needs
(Source)
No matter what type of construction you are undertaking, whether it's a garden patio, driveway repair, or a full-scale construction site, the right tools will make the greatest difference. And when mixing concrete is in question, the concrete mixer is undoubtedly one of the most important tools. However, there are many varieties when it comes to size and type, so how do you find the right one that fits your project?
The question of the size used in concrete mixers is not simply a matter of volume but also involves other factors such as efficiency, cost, and even the quality of the final product. We will make things simple in this guide by cutting through the clutter and helping you make the proper selection of mixer that suits you.
How to Know the Basics of Concrete Mixers
Cement mixers, widely called as concrete mixers, are devices used to blend cement, aggregate, and water to make concrete. They can be found in all shapes and sizes, varying from small, portable ones ideal for DIY projects to huge drum mixers used on commercial projects.
The concrete mixer size is primarily determined by the volume capacity of the drum, measured in litres or cubic meters. It is worth mentioning that the capacity of drums is not directly proportional to the amount of concrete they can mix at a time; typically, they are filled to 60-70% full to allow room for mixing.
The Question of Why Size Matters
Many factors can explain the importance of choosing the correct size:
- Efficiency: A mixer that is too small will require you to batch concrete repeatedly, which slows down your work. Too big, and you are losing resources.
- Quality: a mixer can be overloaded or under-utilised, which means mixes may not turn out the same.
- Labour: Smaller mixers can be time-consuming; large mixers will likely require many people to handle the workload.
- Transport and Storage: Consider where you will use the mixer and how you will store it. Larger units may not be suitable for small areas or those with dwellings.
Choosing the Right Size: Key Factors to Consider
1. Project Scope
Ask yourself: How huge is the task?
- Small jobs (lawn paths, fence posts): For projects that require just a few bags of concrete, a compact mixer with a drum capacity of around 60-120 litres will do the trick. These are regularly electric-powered and, without difficulty, portable.
- Medium jobs (driveways, patios): A mixer with a drum potential of 120-200 litres is more suitable right here. It allows for large batches without overwhelming a one- or two-person team.
- Large-scale projects (foundations, industrial painting): For ongoing and extensive work, a mixer with a capacity of 300 litres or larger, powered by petrol or diesel, is suitable. These machines are constructed for extent and durability.
2. Use Frequency
Single-use "do it yourself" work? It may be a small electric mixer.
A lot of contractor jobs? Buy a mid-sized to large mixer that can withstand regular use.
3. Manpower Available
When mixing alone, it is more challenging to handle a larger mixer.
Bigger mixers can be used and attended by larger teams, resulting in increased uptime throughout the entire project.
4. Time mixing and Output
- The smaller mixers (60-100 litres) typically yield 2 to 3 wheelbarrow loads of concrete with each mix.
- Larger mixers (200-400 litres) may produce 6-10 wheelbarrows in a batch.
To achieve the correct balance, consider how quickly you need to turn out and how long it takes before pouring the next batch of concrete.
Types of Concrete Mixers: A brief overview:
Concrete mixers exist in many forms, which are all applicable in different scales and applications:
1) Batch Mixers (Also Known as Drum Mixers) are used for mixing in drums and are most commonly employed for small to medium-sized projects. They pour a certain amount of concrete into a drum, then pour it out, and another batch is poured in its place.
- Tilt Drum Mixers: The Drum tilts to remove concrete. Excellent as a general-purpose concrete, mortar, and plaster.
- Non-Tilting Drum Mixers: The drum itself rotates on a horizontal axis and features a discharge chute. Frequently applied to greater masses and rigorous mixtures.
- Reverse Drum Mixers: Mixing is achieved by rotating the drum in one direction and then reversing the discharge. Economical with different mixes.
2) Pan Mixers: They possess a fixed pan whereby the blades rotate. Their reputation is high, as it provides a comprehensive and homogeneous mix that is commonly used as a specialist concrete, precast, or high-strength mixes, even within small batches.
3) Continuous Mixers: These continuously load, mix, and discharge concrete, as their name suggests. They are designed to cover huge, constant, and long-term construction projects, such as road paving or bridge construction, where the concrete supply is continuous.
4) Self-Loading Concrete Mixers: These are compact devices that can load, weigh, blend, and discharge concrete on-site. It is ideal for remote locations or projects with varying concrete requirements, appearing as a mobile batching plant.
5) Transit Mixers (Truck Mixers): These are the large trucks you see delivering ready-mix concrete to construction sites. They blend the concrete in transit or maintain it in a state of agitation.
Conclusion
Selecting an appropriate size concrete mixer is a crucial step in achieving a successful concrete pour. Considering the needs of your project, a thorough understanding of the nature and capabilities of the drives on the market, along with practical considerations such as power and portability, will enable you to make an informed decision. Take it right, and your concrete job will become easier, less laborious and yield the level of quality results that your construction project requires.
